Amplificator Multi-Room Streaming Yamaha XDA-QS5400RK

Yamaha
11.499,00 Lei
Amplificator Multi-Room Streaming Yamaha XDA-QS5400RK
Precomanda

Data de livrare: Sambata, 01.06.2024

Limita stoc
Precomanda
Cod Produs: HF0000795 Ai nevoie de ajutor? +40212317631
Adauga la Favorite Cere informatii
  • Descriere
  • Review-uri (0)
Recunoaste fisiere de tip MP3 / WMA / MPEG-4 AAC, ALAC: up to 96 kHz / 24-bit, WAV / FLAC / AIFF: up to 192 kHz 24-bit

Port de retzea Ethernet RJ45 (2 terminale )  AirPlay

Specificatii Audio 8 Canale  (2 canale x 4) Capacitate minimă de încărcare a difuzoarelor 4 ohm

Conesiune Bluetooth

Terminal de ieșire boxe 4 (Euroblock) Preout Terminal 4 Audio Input Terminal RCA:
2 (CUT IN, AUX), USB: 4 Audio Output Terminal RCA (2-ch through out):
2 (CUT IN, AUX) Trigger In / Out 0 / 4 Remote In / Out 1 / 1 Chime 4 Rated Output Power (1 kHz, 0.9% THD, 2ch driven) Normal (4 / 8 ohms): 90 / 50 W, Bridge (8 ohms): 100 W Rated Output Power (1 kHz, 0.9% THD, 1ch driven) Normal (4 / 8 ohms): 100 / 50 W, Bridge (8 ohms):200 W Dynamic Power (20 Hz-20 kHz, 0.08% THD, 2ch driven, 20 ms burst) Normal (4 / 8 ohms): 80 / 40 W, Bridge (8 ohms): 150 W Dynamic Power (1 kHz, 0.9% THD, 2ch driven, 20 ms burst) Normal (4 / 8 ohms): 100 / 50 W, Bridge (8 ohms): 200 W Dynamic Power (1 kHz, 0.9% THD, All ch driven, 20 ms burst) Normal (4 / 8 ohms): 80 / 50 W, Bridge (8 ohms):170 W Maximum Effective Output Power [1-ch driven, 1 kHz, 10% THD] Normal (4 / 8 ohm):130 / 65 W, Bridge (8 ohm): 260 W Total Harmonic Distortion [SP OUT, 20 Hz-20 kHz, 25 W, 8 ohm] 0.04%, [PRE OUT, 20 Hz-20 kHz, 1 V] 0.005% Frequency Response [1 kHz + 0 / -3 dB] PRE OUT NET / USB IN, AUX IN: 10 Hz-22 kHz, SP OUT NET / USB IN, AUX IN: 10 Hz-22 kHz Signal to Noise Ratio [PRE OUT NET / USB IN] 114 dB, [PRE OUT AUX IN] 108 dB, [SP OUT NET / USB IN] 106 dB, [SP OUT AUX IN] 104 dB Rated Output Level / Output Impedance [PRE OUT L / R, 1 kHz] 2.0 V / 470 ohm Maximum Output Level [PRE OUT L / R, 0.9% THD] 4.0 V Maximum Input Signal [PRE OUT L / R, 0.9% THD] 2.4 V Gain [SP OUT 1 V Input] 25.8 dB Input Sensitivity [1 W Power, 8 ohm] 150 mV, [MAX (50W) Power, 8 ohm] 1.0 V Web Setup Yes Direct Mode Yes Monaural Downmix Yes (stereo playback or monaural downmix selectable) Compressed Music Enhancer Yes Volume Adaptive EQ Yes Volume Control Support Terminals: PRE OUT / SP OUT, Range: Mute, -80 dB ~ 0 dB,
Step: 0.5 dB
EQ Characteristics [Bass] Variable Width: +6.0 dB ~ -6.0 dB / 0.5 dB step,
Centre Frequency: 350 Hz, [Mid] Variable Width: +6.0 dB ~ -6.0 dB / 0.5 dB step,
Centre Frequency: 1.1 kHz, [Treble] Variable Width: +6.0 dB ~ -6.0 dB / 0.5 dB step,
Centre Frequency: 3.5 kHz Bass Extension Yes
General Power Consumption 130 W, [All Zone On] No Signal Condition: TBD, [All Zone Off]
Chime On: 18.2 W,
Cut In Power On Enable: 18.2 W
Standby Power Consumption Network Standby Off: 0.2 W,
Network Standby On(1 Zone): 3.2 W,
Network Standby On(All Zone): 6.0 W
Power Management (Auto Power Standby) 5 / 20 min, 2 / 4 / 8 / 12 hours selectable
Dimensiuni (W × H × D) mm
[Table Top Mount with Adhesive Feet] 437 x 46 x 443 mm; 17-1/4” x 1-3/4” x 17-3/8”,
[Table Top Mount with Adhesive Feet and Faceplate] 437 x 46 x 453 mm; 17-1/4” x 1-3/4” x 17-7/8”,
[Rack Mount] 481 x 44 x 443 mm; 18-7/8” x 1-3/4” x 17-3/8”,
[Rack Mount with Faceplate] 481 x 44 x 453 mm; 18-7/8” x 1-3/4” x 17-7/8”
Greutate 6.3 kg; 13.9 lbs.
