Providing access to all yet easily set up, the Duecanali Series is versatile in use. Powersoft's legendary efficiency saves valuable energy, keeping both operational cost and ‘carbon footprint’ at a minimum.
The Duecanali 6404 DSP+D is designed to work with Lo-Z (from 2 Ω ) and with 70V/100V distributed lines: any mixed impedance output loads can be realized.
A fully integrated state-of-the-art DSP yields extensive system management functionality. In addition to sound shaping and limiter functions in unique Powersoft style, the DSP hardware and ArmoníaPlus software enable compliance with IEC 60849 for the crucial requirements of sound systems for emergency purposes.
Data de livrare: Sambata, 01.06.2024
Fully protected circuit design with:
Via software:
Via Hardware:
Output power per Channel | |||
Output power per Channel | 4600 W @ 2 Ω | 3200 W @ 4 Ω | 1800 W @ 8 Ω |
Bridge mode | 9200 W @ 4 Ω | 6400 W @ 8 Ω | |
Max output voltage / current | |||
Maxunclipped output voltage @8 Ω | 175 Vpeak | ||
Current | 110 Apeak | ||
AC MAIN POWER | |||
Power supply | Universal, regulated switch mode with PFC (Power Factor Correction) | ||
Nominal power requirement | 100-240 V ±10%, 50-60 Hz | ||
Operating voltage | 90 V – 264 V | ||
Power consumption /current draw | |||
Idle | 115 V: 33 W – 0.53 A | 230 V: 33 W – 0.37 A | |
1/8 of max output power @ 4 Ω | 115 V: 1073 W – 10 A | 230 V: 1068 W – 5.3 A | |
THERMAL | |||
Operating temperature range | 0° – 45° C – 32° – 113° F | ||
Thermal dissipation | |||
Idle | 115 V: 112 BTU/h | 230 V: 114 BTU/h | |
1/8 of max output power @ 4 Ω | 115 V: 931 BTU/h | 230 V: 913 BTU/h |
